Linksys SRW2024 User Manual

39
Chapter 5: Using the Web-based Utility for Configuration
Statistics Tab - Interface Statistics
16- or 24-Port 10/100/1000 Gigabit Switch with WebView
Statistics Tab - Interface Statistics
The Interface Statistics screen displays statistics for received and transmitted packets.
Interface. Select the appropriate interface, Port, LAG, or VLAN. Then select the appropriate number from the
drop-down menu.
Refresh Rate. Select how often you want the interface statistics refreshed.
Receive Statistics
Total Bytes. This is the number of octets received on the selected interface.
Unicast Packets. Displayed here is the number of unicast packets received on the selected interface.
Multicast Packets. Displayed here is the number of multicast packets received on the selected interface.
Broadcast Packets. Displayed here is the number of broadcast packets received on the selected interface.
Packets with Errors. This is the number of error packets received from the selected interface.s
Transmit Statistics
Total Bytes. This is the number of octets transmitted from the selected interface.
Unicast Packets. Displayed here is the number of unicast packets transmitted from the selected interface.
Multicast Packets. Displayed here is the number of multicast packets transmitted from the selected interface.
Broadcast Packets. Displayed here is the number of broadcast packets transmitted from the selected interface.
Click the Clear All Counters button to reset all statistics to zero.
Figure 5-42: Statistics - Interface Statistics

Linksys SRW2024 Specifications

General

Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
QoS	Yes
Management	Web-based, SNMP
Jumbo Frame Support	Yes
Features	IGMP snooping, Port mirroring, Link aggregation
Power Supply	Internal
Dimensions	440 x 44 mm
Ports	24 x 10/100/1000 Mbps
