Chapter 5: Using the Web-based Utility for Configuration
Statistics Tab - RMON Statistics
16- or 24-Port 10/100/1000 Gigabit Switch with WebView
Statistics Tab - RMON Statistics
The RMON Statistics screen displays information about the Switch’s use and errors. (RMON stands for Remote
Monitoring.)
Interface. Select the appropriate interface, Port, LAG, or VLAN. Then select the appropriate number from the
drop-down menu.
Refresh Rate. Select how often you want the interface statistics refreshed.
Drop Events. This is the number of dropped events that have occurred on the interface since the Switch was last
refreshed.
Received Bytes. This is the number of octets received on the interface since the Switch was last refreshed. (This
number excludes framing bits.)
Received Packets. This is the number of packets received on the interface since the Switch was last refreshed.
Broadcast Packets Received. This is the number of good broadcast packets received on the interface since the
Switch was last refreshed. (This number excludes multicast packets.)s
Multicast Packets Received. This is the number of good multicast packets received on the interface since the
Switch was last refreshed.
CRC & Align Errors. This is the number of CRC and Align errors that have occurred on the interface since the
Switch was last refreshed.
Undersize Packets. This is the number of undersized packets (fewer than 64 octets) received on the interface
since the Switch was last refreshed.
Oversize Packets. This is the number of oversized packets (over 1518 packets) received on the interface since
the Switch was last refreshed.
Fragments. This is the number of fragments (packets with fewer than 64 octets, excluding framing bits) received
on the interface since the Switch was last refreshed.
Jabbers. This is the total number of received packets that were longer than 1518 octets. (This number excludes
framing bits.)
Collisions. This is the number of collisions received on the interface since the Switch was last refreshed.
Figure 5-44: Statistics - RMON Statistics

Linksys SRW2024 Specifications

General

Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
VLAN Support	Yes
QoS	Yes
Management	Web-based, SNMP
Jumbo Frame Support	Yes
Features	IGMP snooping, Port mirroring, Link aggregation
Power Supply	Internal
Dimensions	440 x 44 mm
Ports	24 x 10/100/1000 Mbps
