WAP4410N User Guide 80
Specifications
WAP4410N Specifications
Model
WAP4410N
Standards Draft IEEE802.11n, IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u,
IEEE802.3af (Power Over Ethernet), 802.1x (Security Authentication),
802.11i Security WPA/WPA2, WMM
Ports Ethernet, Power
Buttons Reset
Cabling Type UTP Cat 5e or higher
LEDs Power, Ethernet, Wireless, POE
Operating System Linux
Web UI Built in Web UI for Easy browser-based configuration (HTTP/HTTPS)
SNMP Version Version 1, 2c, 3
Event Logging Email logging, Remote Syslog
Web F/W Upgrade Firmware Upgradeable Through Web-Browser
Diagnostics, Flash,
etc
Flash, RAM, LAN, WLAN
DHCP DHCP Client
HTTP Redirect Redirects initial user access to an external Web Server to display
company logo or network usage policy
IPv6 Host Support for management and control of Access Point over IPv6.
Supports RFC2460 (IPv6 protocol) and RFC4294 (IPv6 Node
Requirements)
Multiple BSSID Supports up to 4 BSSIDs allowing creating of multiple virtual Access
Points
VLANs Supports 802.1q - up to 4 VLANs
SSID to VLAN
mapping
Supports mapping of SSIDs to VLANs to securely separate
workgroups across wireless and wired domains
802.1x Supplicant Supports 802.1x Supplicant on the Ethernet port to allow the AP to
authenticate itself to the network
Spanning Tree Supports 802.1d Spanning Tree protocol to prevent loops when
using WDS links as redundant links in a distribution system
