Operating Manual
Cross-flow fan unit type GSG-NV1 / 2
10 - 64
010980-26-E BA GSG-NV1_2 / 23.03.2012
6. Construction details of the GSG-NV / standard equipment
frame with double-coat paint RAL 6011
cross-flow fan unit width adjustment (infinitely variable / common
or single action) and drawbar adjustment with hydraulic cylinder,
both electrically controlled by control unit, including control box for
tractor cabin
hydraulic drawbar for tight turning radius and front support
adjustable axle, with mechanical clamping
2 (one row) / 4 (two rows) hydraulic driven cross-flow fans,
equipped with collecting tray and hydro injector for the leading
back of the unused liquid - minimum operating pressure 5 bar re-
quired for suction
one V4A nozzle tube each integrated in the cross-flow fans,
with 5 drip-stop rotary nozzle bodies with flat fan venturi nozzles
(AVI 80° green or other output quantities on request) individu-
ally adjustable
pressure filter (80 mesh), suction filter (50 mesh) and recycling
filter (50 mesh)
1000 liter tank with tank cleaning nozzle and injector agitator,
water jet mechanism integrated in filling screen
100 l fresh water tank with 3-way tap for switching for cleaning the
equipment and 15 l hand-washing container integrated in 1000 l.
tank
full electrical control: Nozzles, recycling, pressure and agitator
can be controlled via control box on tractor, manometer built into
control box
12V lighting in accordance with motor vehicle regulations
tires 10.0 / 75-15.3 tt 8 PR
160 l. pump, 16 bar
universal joint shaft
