liquidarc Maxmig 210i - Page 25

IMA 578BLA Maxmig 210 Page 25
# Indicates a change this printing.
* Items not illustrated.
ITEM DESCRIPTION PART NO. QTY. 123456789
1 Front Panel AL2532-7 1 x
2 Indicator - Over Temp AS4460-1 1 x
3 Pilot Light AT3384-1 1 x
4 Moulded Output Stud AM2464-1 2 x
5 Flange Nut T3960 2 x
6 Toggle Switch AT3440 1 x
7 Rotary Switch AM3388-3 1 x
Use only the parts marked “X” in the column under the
heading number called for in the model index page.
AP-95-D1
Operative: 4.7.03
Supersedes: 28.10.98
Recommended Spare Parts are highlighted in bold
Nut, bolt and washer sizes are given so they may be procured locally.
