LIXiSE LXC3120 User Manual

LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 16 of 28
Delay
under voltage.
23
Gen Over Voltage
(30-620)V
264
When generator voltage has exceed the set value
and the “Gen abnormal delay” has expired, Gen
Over Voltage is active. When set the value as
620V, the controller does not detect over voltage
signal.
24
Generator Under
Voltage
(30-620)V
196
When generator voltage has fallen below the set
value and the “Gen abnormal delay” has expired,
Gen Under Voltage is active. When set the value
as 30V, the controller does not detect under
voltage signal.
25
Under Speed
(0-6000)RPM
1200
When engine speed has fallen below the set value
for 10s, Under Speed is active. It will initiate a
shutdown alarm signal.
26
Over Speed
(0-6000)RPM
1710
When engine speed has exceed the set value for
2s, Over Speed is active. It will initiate a shutdown
alarm signal.
27
Under Frequency
(0-75.0)Hz
45
When generator frequency has fallen below the
set value but Not equal to 0 for 10s, Under
Frequency is active. It will initiate a shutdown
alarm signal.
28
Over Frequency
(0-75.0)Hz
57
When generator frequency has exceed the set
value for 2s, Over Frequency is active. It will
initiate a shutdown alarm signal.
29
High Temperature
(80-140)ºC
98
When the temperature value of the external
temperature sensor exceeds the set value, high
temperature signal is sent. Detecting only after
safety on delay is over. If the set value is 140, high
temperature signal will not be sent (this only
concerns external temperature sensor, not high
temperature signal via configuration. input port).
30
High Temperature
Action
(0-1)
0
0：Warning 1：Shutdown.
31
Low Oil Pressure
(0-400) KPa
103
When the external pressure sensor value falls
below this set value, low oil pressure signal is
sent. Detecting only after safety on delay is over. If
the set value is 0, low oil pressure signal will not
be sent (this only concerns pressure sensor and
does not concern low oil pressure warning signal
via configurable input port).
32
Low Oil Pressure
Action
(0-1)
0
0：Warning 1：Shutdown.
33
Loss of Speed
Signal
(0-20.0)s
5
If the set value is 0, only warning and not to
shutdown the generator.
34
Charge Alt Failure
（Warning）
(0-30)V
6
During generator is normal running, when
alternator D+(WL) voltage has fallen below the set
value and remains for 5s, It generates charging
failed warning.（Return value is 1V）
35
Battery Over Voltage
（Warning）
(12-40)V
33
When battery voltage has exceeds the set value
and remains for 20s, It will initiate a warning alarm
signal. Only warning and not to shutdown the
generator.
（Return value is 1V）
36
Battery Under
Voltage（Warning）
(4-30)V
8
When battery voltage has fallen below the set
value and remains for 20s, It will initiate a warning
