LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 17 of 28
alarm signal. Only warning and not to the
generator.
（Return value is 1V）
37
Current Trans.
(5-6000)/5
500
The ratio of external CT .
38
Full Current Rating
(5-6000)A
500
Generator’s rated current, standard of load
current.
39
Over Current
Percentage
(50-130)%
120
When the load current has exceed the set value,
“over current” delay is initiated.
40
Over Current Delay
(0-3600)s
1296
When load current has exceed the set value and
the “over current” delay has expired, over current
is initiated. When the set value is 0, only warning
and not to shutdown the generator.
41
Gens on load
Frequency
(0-75.0)Hz
45
When the generator to load conditions (load
frequency / load / voltage / load speed), begin to
load transfer (Gens load action).
42
Gens on load Volt
(30-620)V
196
43
Gens on load Speed
(0-6000)RPM
1200
44
Digital Output 1
(0-74)
1
Factory default: Fuel Relay Output
45
Digital Output 2
(0-74)
13
Factory default: Energized To Stop
46
Digital Output 3
(0-74)
10
Factory default: Idle Control
47
Digital Output 4
(0-74)
14
Factory default: Close Generator
48
Digital Output 5
(0-74)
19
Factory default: Mains Closed
49
Digital Input 1
Type
(0-29)
3
Factory default: High Temperature Input
50
Digital Input 1 Active
(0-1)
0
Factory default: Close to active
51
Digital Input 1 Action
(0-2)
Never/Warning/Shutdown
52
Digital Input 1 Period
(0-3)
Never/From safety on/From Crank/Away.
53
Digital Input 1 Delay
(0-20.0)s
Delay output function.
54
Digital Input 2
Type
(0-29)
4
Factory default: Low Oil Pressure Warning Input.
55
Digital Input 2 Active
(0-1)
0
Factory default: Close to active.
56
Digital Input 2 Action
(0-2)
Never/Warning/Shutdown.
57
Digital Input 2 Period
(0-3)
Never/From safety on/From Crank/Away.
58
Digital Input 2Delay
(0-20.0)s
Delay output function.
59
Digital Input 3 Type
(0-29)
10
Factory default: Remote Start.
