LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 10 of 28
7
Battery Under
Volt
When the controller detects that battery voltage has fallen below the pre-set
value, it will initiate a warning alarm and the corresponding alarm information will
be displayed on LCD.
8
Battery Over
Volt
When the controller detects that battery voltage has exceeded the pre-set value, it
will initiate a warning alarm and the corresponding alarm information will be
displayed on LCD.
9
Auxiliary Input
When the controller detects that the auxiliary input warning signals, it will initiate a
warning alarm and the corresponding alarm information will be displayed on LCD.
10
Loss Of
Speed
Signal
When the controller detects that the engine speed is 0 and the delay is 0,it will
initiate a warning alarm and the corresponding alarm information will be displayed
on LCD.
11
Low Coolant
Level
When the controller detects the low coolant level input is active, it will initiate a
warning alarm and the corresponding alarm information will be displayed on LCD.
12
Temp. Sensor
Open
When the controller detects that the temperature sensor is open circuit and the
action select “Warn”, it will initiate a warning alarm and the corresponding alarm
information will be displayed on LCD.
13
Oil Pressure
Sensor Open
When the controller detects that the oil pressure sensor is open circuit and the
action select “Warn”, it will initiate a warning alarm and the corresponding alarm
information will be displayed on LCD.
5.2. Shutdown alarm
When controller detects shutdown alarm, it will send signal to open breaker and stop the genset. The
alarm information will be displayed on LCD.
Shutdown alarm types are as follows：
No.
tems
Description
1
Digital
Input
When digital input port is set as shutdown, and the action is active, it will send a
shutdown signal.
2
High
Temperatu
re
When controller detects that the water/cylinder temperature has exceeded the
pre-set value, it will initiate a shutdown alarm and the corresponding alarm
information will be displayed on LCD.
3
Low Oil
Pressure
When the controller detects that the oil pressure has fallen below the pre-set value,
it will initiate a shutdown alarm and the corresponding alarm information will be
displayed on LCD.
4
Over
Speed
When the controller detects that the generator speed has exceeded the pre-set
value, it will initiate a shutdown alarm and the corresponding alarm information will
be displayed on LCD.
5
Under
Speed
When the controller detects that the generator speed has fallen below the pre-set
value, it will initiate a shutdown alarm and the corresponding alarm information will
be displayed on LCD.
6
Loss Of
Speed
Signal
When the controller detects that the engine speed is 0 and the delay is NOT 0, it will
initiate a shutdown alarm and the corresponding alarm information will be displayed
on LCD.
7
Gen Over
Voltage
When the controller detects that the genset voltage has exceeded the pre-set
value, it will initiate a shutdown alarm and the corresponding alarm information will
be displayed on LCD.
8
Gen Under
Voltage
When the controller detects that the genset voltage has fallen below the pre-set
value, it will initiate a shutdown alarm and the corresponding alarm information will
be displayed on LCD.
