Withdraw Voltage Test
When controller had been installed in control panel, if need the high voltage test, please disconnect
controller’s all terminal connections, in order to prevent high voltage into controller and damage it.
11. Fault finding
Following in my controller process more common failure and troubleshooting, if there is a failure of the
other can not be solved, please contact my company.
Symptom
Possible Remedy
Controller no response with
power.
Check starting batteries;
Check controller connection wirings;
Check DC fuse.
Genset shutdown
Check the water/cylinder temperature is too high or not;
Check the genset AC voltage;
Check DC fuse.
Controller emergency stop
Check emergence stop button is correct or not;
Check whether the starting battery positive be connected with the
emergency stop input;
Check whether the circuit is open.
Low oil pressure alarm after crank
disconnect
Check the oil pressure sensor and its connections.
High water temp. alarm after
crank disconnect
Check the temperature sensor and its connections.
Shutdown Alarm During Running
Check related switch and its connections according to the
information on LCD;
Check auxiliary inputs.
Crank not disconnect
Check fuel circuit and its connections;
Check starting batteries;
Check speed sensor and its connections; Refer to engine manual.
Starter no response
Check starter connections;
Check starting batteries.
Genset running while ATS not
transfer
Check ATS;
Check the connections between ATS and controllers.
12. Product packaging
This product should be following sets:
(1) 1 piece of controller
；
(2) 2 pieces of fixed cards；
(3) 1 piece of Shockproof rubber ring
；
(4) 1 piece of product certificate；
(5) 1 piece of product mutual.
