LIXiSE LXC31X0 Series User Manual

LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 15 of 28
4
Mains Under
frequency
(0-75.0)Hz
45
When mains frequency has fallen below the set
value, Mains Under frequency is active. When set
the value as 0V, the controller does not detect
under frequency signal. Back lash: 2V (delay of 1
second)
5
Mains Over
frequency
(0-75.0)Hz
57
When mains frequency has exceed the set value,
Mains Over frequency is active. When set the
value as 75V, the controller does not detect over
frequency signal. Back lash: 2V(delay of 1 second)
6
Transfer Time
(0-99.9)s
1
Interval time from mains switch off to generator
switch on; or from generator switch off to mains
switch on.
7
Start Delay
(0-3600)s
1
Time from mains abnormal or remote start signal
is active to start genset.
8
Stop Delay
(0-3600)s
1
Time from mains normal or remote start signal is
deactivated to genset stop.
9
Start number
(1-10)
3
Maximum crank times of crank number. When
reach this number, controller will send start failure
signal.
10
Preheat Delay
(0-300)s
0
Power-on time of heater plug before starter is
powered up.
11
Cranking Time
(3-60)s
8
Power-on time of starter.
12
Crank Rest Time
(3-60)s
10
The waiting time before second power up when
engine start fail.
13
Safety On Delay
(1-60)s
10
Alarms for low oil pressure, high temperature,
under speed, under frequency / voltage, charge alt
failure are inactive.
14
Start Idle Time
(0-3600)s
0
Idle running time of genset when starting.
15
Warming Up Time
(0-3600)s
10
Warming time between genset switch on and high
speed running.
16
Cooling Time
(3-3600)s
10
Radiating time before genset stop, after it unloads.
17
Stop Idle
(0-3600)s
0
Idle running time when genset stop.
18
ETS Solenoid
Hold
(0-120)s
20
Stop electromagnet’s power on time when genset
is stopping.
19
Fail to Stop Delay
(0-120)s
0
Time between ending of genset idle delay and
stopped when “ETS time” is set as 0; Time
between ending of ETS hold delay and stopped
when “ETS time” is not 0.
20
Close Time
(0.1-100.0)s
5
Pulse width of mains/generator switch on.
21
Flywheel Teeth
(5-300)
118
Tooth number of the engine, for judging of starter
crank disconnect conditions and inspecting of
engine speed. See the installation instructions.
Tooth number of the engine, for judging of start
er crank disconnect conditions and inspecting of
engine speed. See the installation instructions.
(When genset has no magnetic sensor,please
set to 5 to close magnetic sensor)
22
Gen Abnormal
(0-20.0)s
10
The alarm delay of generator over voltage and
