LIXiSE LXC31X0 Series User Manual

LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 18 of 28
60
Digital Input 3 Active
(0-1)
0
Factory default: Close to active.
61
Digital Input 3Action
(0-2)
Never/Warning/Shutdown.
62
Digital Input 3 Period
(0-3)
Never/From safety on/From Crank/Away.
63
Digital Input3 Delay
(0-20.0)s
Delay output function.
64
Digital Input 4
Type
(0-29)
0
Factory default:User Configured
65
Digital Input 4 Active
(0-1)
0
Factory default: Close to active
66
Digital Input 4 Action
(0-2)
1
Never/Warning/Shutdown.
67
Digital Input 4 Period
(0-3)
2
Never/From safety on/From Crank/Away.
68
Digital Input3 Delay
(0-20.0)s
2
Delay output function
69
Power On Mode
(0-2)
0
0：Stop Mode 1：Test Mode 2：Manual Mode 3：
Auto mode.
70
Module Address
(1-247)
1
Communication address of controller.
72
technician password
(0-9999)
1
The technician password authorization,Has the
authority to modify all parameters.
73
operator password
(0-9999)
2
The operator password can only observe the
configuration parameters, and cannot be modified.
74
Crank Disconnect
(0-8)
6
There are 3 conditions of disconnecting starter with
engine. Each condition can be used alone and
simultaneously to separating the start motor and
genset as soon as possible.
75
Disconnect
Engine Speed
(0-3000)RPM
360
When engine speed higher than the set value,
starter will be disconnected.
76
Disconnect
Generator Freq
(10.0-30.0)Hz
14
When generator frequency higher than the set
value, starter will be disconnected.
77
Disconnect Oil
Pressure
(0-400)KPa
200
When generator oil pressure higher than the set
value, starter will be disconnected.
78
D+
Disconnect
(3.0-32.0)V
8
When generator D+ higher than the set value,
starter will be disconnected.
79
Voltage Input
(0-3)
0
0: 3P4W; 1: 2P3W
2: 1P2W; 3: 3P3W Note 3
80
Poles
(2-16)
4
81
Temp. Sensor
Curve
(0-9)
1
VDO120ºC
82
Oil Pressure
Sensor Curve
(0-9)
1
VDO0-10BAR
83
Temperature
Sensor Open
(0-2)
1
0: Never (temperature sensor will show “+++”);
1:Warn; 2:Shutdown
84
Oil Pressure
Sensor Open
(0-2)
1
85
Configuration
Sensor Curve
(0-1)
0
Temperature and oil pressure sensor curve can be
defined.
86
Parameters
selection
Enter the parameter number, press confirm to
quickly jump to the parameter setting items.
