LIXiSE LXC31X0 Series User Manual

LXC31X0/LXC93X0 Generator controller user manual
Dongguan Tuancheng Automation Equipment Co.,LTD.
LXC31X0/LXC39X0 User Manual Dongguan Tuancheng Automation Equipment Co.,LTD.
: T:+86 769-23162896 : F:+86 769-23166296  :www.lixise.com Page 21 of 28
27
In Stop Mode
28
In Manual Mode
29
In Manual Test Mode
30
In Auto Mode
31
Generator On Load
32
Mains On Load
33
Common Alarm
Action in gens common warning,common shutdown, common trips alarm.
34
Common trip shutdown
The generators any kind of trip and downtime will produce such an
alarm action.
35
Common Shutdown
Generator any downtime will have such alarm action.
36
Common Trip Alarm
Generators will produce any kind of trip the alarm action.
37
Common Warn Alarm
Generators of any kind of public warning alarm is generated action.
38
Battery Hight Voltage
An action in battery’s over voltage warning alarm.
39
Battery Low Voltage
Action in battery’s low voltage warning alarm.
40
Charging failure
Action in charge alt fail warning alarm.
41
Emergency Stop
Action in emergency stop alarm.
42
Failed To Start
Action in failed start alarm.
43
Failed To Stop
Action in failed stop alarm.
44
Under Speed Warn
Action in under speed warning.
45
Under Speed Shutdown
Action in under speed shutdown.
46
Over Speed Warn
Action in over speed warning.
47
Over Speed Shutdown
Action in over speed shutdown alarm.
48
Gens Over Freq Warn
Action in gens over frequency warning.
49
Gens Over Freq Shutdown
Action in gens over frequency shutdown alarm.
50
Gens Over Volt Warn
Action in gens over voltage shutdown.
51
Gens Over Volt Shutdown
Action in gens low frequency warning.
52
Gens Under Freq Warn
Action in gens low frequency shutdown.
53
Gens Under Voltage Warn
Action in gens low voltage warning.
54
Gens Under Volt Shutdown
Action in gens low voltage shutdown.
55
Gens Under Volt Shutdown
Action in gens low voltage shutdown.
56
Gens Loss Of Phase
Action in gens loss phase.
57
Gens Reverse Phase
Action in gens reverse phase.
58
Over Current
Action in over current.
59
Mains Inactive
Action in mains Inactive .
60
Mains Over Freq
Action in mains over frequency.
61
Mains Over Voltage
Action in mains over Voltage.
62
Mains Under Freq
Action in mains under frequency.
63
Mains Under Volt
Action in mains under Voltage.
64
Mains Reverse Phase
When phase sequence of 3 phase input mistake.
65
Mains Loss Of Phase
Action in mains loss Of Phase.
66
High Temp Warn
Action in low temperature warning alarm.
67
High Temp Shutdown
Action in high temperature Shutdown alarm.
68
Low Oil Pressure Warn
Action in low oil pressure warning alarm.
69
Low Oil Pressure Shutdown
Action in low oil pressure shutdown.
70
OP Sensor Open
Action when oil pressure sensor are open circuit.
71-74
Aux Input 1-4Active
