6 Instruction Manual
*Proportional
10ft (3m)
*ON / OFF
12in (304.8mm)
pH Electrode
(BNC Connector)
Output Wiring
for Options
Power Cord
6ft (1.8m)
BOTTOM VIEW
Input / Output
Wiring for Options
Base Pump Output*
Acid Pump Output*
Power Cord
Figure 4. Electrode and Pump Connections
