Instruction Manual
SECTION 9 - PARTS LIST
Key No. Part No. Description
1 34691 Housing, Machined
2 32186 Screw, 4-40 x 0.37
3 32187 Nut, 4-40 Flush
4 32209 Latch, Machined
5 34270 I/O Board Assembly
6 34716 Standoff, Self Adhesive
7 31632 Screw, #6 x 0.38
8 34329 BNC Cable Assembly
9 34330 Ribbon Cable Assembly
10 25957-1 Cord Clamp (PG-9) Clamp for female outlet power cord)
11 36810 Dowel
12 31571 Clamp, Cord (PG-9) Clamp for 4pin cable
13 34074 Gasket, Foam
14 34088 Cover, Utility Box
15 30588 Label LMI Logo
16 37524 Front Panel Assembly
17 31617 Cover, Liquitron™
18 32094 Label, Housing cover LMI
19 32211 Cap, 0.125 x 0.38
20 32352 O-Ring, Sponge
21 32395 Screw, Self-Tapping
23
48461 Cord, Power, 115V, NEMA 15-R - DP5000-XA (ON / OFF)
33636 4-Pin Cable - DP5000-XB (Proportional)
24 34930 Terminal Cover Label
26
30749 Power Cord 115V - DP5000-1A/B
30751 Power Cord 220V US - DP5000-2A/B
30752 Power Cord DIN - DP5000-3A/B
34783 Cord Assembly UK - DP5000-5A/B
30754 Power Cord AUST - DP5000-6A/B
34784 Cord Assembly SWISS - DP5000-7A/B
27 37830 4-20mA Circuit Board Assembly
