22
Instruction Manual
SECTION 4 - OPERATION
Similarly, the Pump Control Points can be displayed
while in the ‘RUN’ Mode by pressing the ‘Pump A’
or ‘Pump B’ keys once.
Press
ACID
PUMP A
and the following screens display:
Pump A
10
Pulses / Min
7.6
pH
Set Point 1
+ 3 Seconds
Pump A
100
Pulses / Min
9.6
pH
Point 2
4.6 ADVANCED MENU
Holding the
DISPLAY
key for ve (5) seconds accesses
the ‘Advanced Features’ Menu, and allows these
settings to be changed.
Press the ‘DISPLAY / MENU’ key for five (5)
seconds while the controller is in the ‘EDIT’ or
‘OFF’ mode.
The rst item displayed is the software revision.
Pressing ‘Display / Menu’ again cycles to the rst
option. The rst number is the option. The second is
the setting. Use the
or to change the setting.
OPTION SETTING
1 1 Control returns to Run 60 seconds after last keypress
0 Run/Edit key is On/Off
2 1 On/Off Control
0 Proportional Control (and On/Off)
2 Proportional Control
3 1 Point 3 Programming Enabled
0 Point 3 Programming Disabled (Two point only)
4 1
Solenoid programmed to switch on after programmed
time‘DELAY 1’ and to switch Off after programmed time ‘DELAY 2’
0 Solenoid Disabled
5 1
(NA)
0
6 1 mA Enabled - Option Board must be tted
0 mA Disabled
7 1 Allows editing of #5 & #6
0 Lockout #5 and #6
NOTE:
The Option Board (37830) is required for
Option 6.
