SECTION 7 - DP5000 SPECIFICATIONS
LCD Display
Operating Voltage: 5 V
Operating Temperature 32° F to +122° F (0° C to +50° C)
Viewing Area: 1.2 x 1.8 inches (30 x 46 mm)
Backlight: An 8 emitter (dual LED type), double row, reective backed, backlight
module will be used. The light output color and reective backing color will be
high performance green.
Memory Backup
EEPROM
Data Retention No Power: 10 year minimum
Pre-amplier Output
Voltages
Voltage: ± 5 V
Output Voltage Tolerance: ± 5% maximum
Current Output: ± 10 mA maximum
Optional
Output
4-20 mA Load: 500 Ω maximum resistance
Accuracy: ± 0.2 mA - The 4-20 mA isolated
Control
Outputs
(Pump A / Pump B) (Proportional Control): Opto-Isolated Open Collector (2 mA)
Fault: Opto-Isolated Open Collector (2 mA)
Control
Inputs
Remote ON / OFF: Opto-Isolated (2 mA)
Flow Switch: Opto-Isolated (2 mA)
Low Level Input: Opto-Isolated (2 mA)
Aux (spare): Opto-Isolated (2 mA)
Environmental
Printed Circuit Boards conformally coated
Operating Temperature: 32°F to 122°F (0°C to 50°C)
Enclosure: IEC IP65, NEMA 4X
Mechanical
Two printed circuit boards (3 if option installed)
Control Board: (Microcontroller & Display) - Low Voltage
Terminal / Power Board: Transformer, fuses, terminal blocks, relays
Option Board: (4-20 mA output ) - Low Voltage
