START UP MANUAL 1
QUICK LOAD SERVO III
E-1
10.13.06
TABLE OF CONTENTS
1. STARTING THE BAR FEED SYSTEM 2
1.1 Description 2
2. SETTINGS RELATED TO INSTALLATION 3
2.1 End of bar position 3
2.2 Top-cut position 6
3. SETTINGS RELATED TO BAR STOCK AND MACHINED PARTS 8
3.1 Example 1: Set-up for round bars 8
3.2 Example 2: Set-up for hexagonal bars 10
3.3 Example 3: Set-up for square bars 12
3.4 Example 4: Set-up for "others" bars 14
4. MECHANICAL SETTINGS AND OPTIONAL ACCESSORIES 16
4.1 Replacement of the feeding pusher 16
4.2 Slope of the magazine table 19
4.3 Settings of the loading fingers 20
4.4 Settings of the loading table 20
5. PUTTING THE LATHE INTO OPERATION 22
5.1 Spindle reduction tubes 22
5.2 Optional accessories for profiled bars 23
