LNS QUICK LOAD SERVO S3 - 3 Settings Related to Bar Stock and Machined Parts

8 START UP MANUAL
QUICK LOAD SERVO III
Note :
For more
information
concerning
the
parameters,
see Chapter 7,
point 5.
3. SETTINGS RELATED TO BAR STOCK AND MACHINED PARTS
3.1 Example 1: Start-up for round bars
Specifications
Bar profile Round
Bar diameter 20.0 mm
Length of pieces to be machined 55.0 mm
Thickness of the cutoff tool 2.0 mm
a) Set-up of parameters :
Conditions: The loading table is in low position
2 bars of the new diameter are on the loading table
Bar feeder in STOP mode
Press the [MENU] key; the remote command displays the following text :
Press the [1] key; the remote
command displays the following text :
MAIN MENU
1: PART SETUP
2: APPLICATION SETUP
3: POSITION/TORQUE
4: MISCELLANEOUS
FUNCTIONS
5: SERVICE
LOADING OF:
[@]
1: ROUND MATERIAL
2: HEXAGONAL
3: SQUARE
4: OTHERS PRM87
