LNTECH SLA-3 User Manual

13
Mark Function Instruction Remark
E1/E2/E3
Woring status: proper alignment,
indicators (green LED) ONAdjustmen
mode: proper alignment, indicators
(green LED) OFF
Muting
indication
Receiver is muted,indicator(yellow)
asing
Power Power on, indicator(red) ON
Fault
indicator
Wrong wiring or receiver fault, indicator
(yellow) ashing
refer to
troubleshooting
Pedal switch Pedal connection,indicatro(green) ON
Slow speed
close
Low speed signal connection, indicator
(green) ON
OSSD1
Receiver output signal connection,
indicator (greeen) ON
Safety output
OSSD2
Receiver output signal connection,
indicator (greeen) ON
Safety output
Slow speed
clos output
Compulsory low speed output(special
mode PNP output), indicator(green) ON
Auxiliary
output
Auxiliary indication and EDM
off,indicator(green) ON
not used for
protection
Adjustment
mode
Sensors adjustment,proper alignment
indicator(green) ON
Flat bending
mode
Proper alignment indicator(green) ON
Box bending
mode
Proper alignment indicator(green) ON
Special mode Proper alignment
，
indicator(green) ON
Mode change
access
Switch to green point ON, allow to
change mode
Mode option
select mode change access at ON, then
push down the option button,can select
working mode
3.1 Receiver Indicators
