14
◆
To carry out the installation, connection, commissioning and
maintenance of SLA-3 device by qulied person
◆
This warranty does not cover damage or liability for misuse, abuse,
or the improper application or installation
4.1 Safety Distance
The safety distance is the vertical line distance (S) from upper tool tip
to the bottom beam(E2), which is the min. distance allowed between
protection device and the dangerous area
The mounting position must be in line with the safety distance
requirements,otherwise may lead to serious injury
4 Installation
（
mm
）
Emitter Receiver
