25
5.check the slow speed closing wiring correct,i.e. orange, orange/green
cable
6.check the muting wiring correct,i.e. red/green, blue/green cable
7.After the above wiring, operate the bending machine with full stroke
to check and conrm the SLA-3 device output and indicators display
normally
8. Connect the output1, output2 with bending machine control system,
control the machine and check if works normally or not
5.4 Signal Cable
Part Color Function Remark
Emiter
Brown DC24V VCC
White COM LOC
Blue GND 0V
Yellow/Green AG auxiliary GND
Receiver
Brown DC24V VCC
White COM LOC
Blue GND 0V
Purple Pedal NO pedal signal
Grey Pedal NC pedal signal
Orange Slow speed NO1 slow speed signal
Orange/Green Slow speed NO2 slow speed signal
Red/Green Mute NO1 muting signal
Blue/Green Mute NO2 muting signal
White/Green Slow speed output PNP
Red EDM input EDM
Black/Green Auxiliary output not a safety output
Green OSSD1 safety output
Black OSSD2 safety output
Yellow/Green AG auxiliary GND
