Fig.4-8 Installation Bracket
1. Adjustment bracket
2. Screw M6*12
vertical view
3
rd
step: receiver mounting bracket
1.Screw M8*20
2.Fixed bracket 1
3.Fixed bracket 2
4.Screw M6*12
Fig.4-9 Receiver Mounting Bracket
