Menu - antenna (ANA)
Go to: LOC HOA HOB TVA TVB RA VD SRA SRB MB EP AF PI AU ST CTA CTB NMA NMB NMC COA COB COC COD ANA ANB EX MU HOT SVA
Antenna
DVB-S
Antenna
DVB-T
No supply
voltage
Supply
voltage 5V
ANTENNA_WIZARD - Current settings
Proceed with End with BACK
The following system has been set:
Satellite system
Dual/singel band
LNC frequency low/high
XXXXXXXXX
XXXXXXXXX
XXXXXXXXX
Number of satellite antenna cables
Back with Proceed with
If you have 2 satellite antenna cables .....
Only one antenna cable Two antenna cables
Select satellite installation
Back with Proceed with
Please indicate here which satellite system ....
Single satellite
2 satellites on 22kHz switchbox
2 satellites on toneburst switch
Max. 4 satellites on DiSEqC multiswitch
DiSEqC unicable communal system
Other communal installation
Select satellites
Back with Proceed with
Please specify here which satellite ....
Optus D1 160°E
Türksat 42°E
Hellas Sat2 39°E
:
ASTRA1 19,2°E
Eutelsat 16A 16°E
Hot Bird 13°E
:
Eutelsat 5
Nilesat 7°
Eutelsat 7
:
Dual/single band (satellite x)
Back with Proceed with
here, please specify whether .....
Dual band (low/high) Single band
LNB frequencies
Back with Proceed with
Please select the LNB frequency .....
Satellite X low band 9750MHz 10000MHz 10200MHz
LNB frequencies
Back with Proceed with
Please select the LNB frequency .....
Satellite X low band 9750MHz 10000MHz 10200MHz
Satellite X high band 10600MHz 10750MHz 11000MHz
Select satellites
Zurück mit Weiter mit
Please select satellite 1 and satellite 2.
Satellite 1 Satellite 2
ASTRA3 23,5°E
ASTRA1 19,2°E
Eutelsat 16A 16°E
:
keiner
Optus D1 160°E
Türksat 42°E
:
Thor/Intel
Eutelsat 5
Nilesat 7°
:
LNB frequencies
Back with Proceed with
Please select the LNB frequency .....
Satellite 1 low band 9750MHz 10000MHz 10200MHz
Satellite 2 low band 9750MHz 10000MHz 10200MHz
Select satellites
Back with Proceed with
Please select satellite 1 and satellite 2.
Satellite 1 Satellite 2
ASTRA3 23,5°E
ASTRA1 19,2°E
Eutelsat 16A 16°E
:
keiner
Optus D1 160°E
Türksat 42°E
:
Thor/Intel
Eutelsat 5
Nilesat 7°
:
LNB frequencies
Back with Proceed with
Please select the LNB frequency .....
Satellite 1 low band 9750MHz 10000MHz 10200MHz
Satellite 1 high band 10600MHz 10750MHz 11000MHz
Satellite 2 low band 9750MHz 10000MHz 10200MHz
Satellite 2 high band 10600MHz 10750MHz 11000MHz
ANA1 ANA2
ANB1
ANB2
ANB3
