Loewe bild 5 oled / bild 4 oled
User handbook
21
Initial installation
Setting options for DVB-T reception:
If you have not selected Terrestrial (DVB-T) in step Connect
antenna cable(s) in the initial installation, proceed to the next section
Setting options for DVB-C reception.
If several networks are available via DVB-T, you can
decide which network you want to receive your
channels from.
Select network,
OK Confirm selection.
Proceed to next step.
Select and adapt settings for DVB-T reception.
OK Confirm selection.
Scrambled
stations
You can state whether coded stations are to be
searched for in the search/update.
Select yes to save all found scrambled stations.
However, these stations can only be received in
connection with a CA module and the appropriate
Smart Card.
The handling of the CA module is described in the
chapter System settings, section Extras – CA
module.
Search
method
If you want to run the station search independently
of the channel grid, select Frequency search for
the search method.
Accept
Logical
Channel
Number
In various countries, digital stations (DVB-T) are
transmitted with a preset channel number per
station, known as Logical Channel Numbers (LCN).
If you select yes here, these default channel slots
will be used and the channels of the preferred signal
source will be sorted as per LCN. The stations in the
station list can no longer be shifted.
Network
selection
Please state from which network you wish to receive your station.
Note: The newly selected parameter must be confirmed with the button.
Freeview
other network
Network selection (DVB-T)
Back with Proceed with
OK
Settings
Supply
voltage
DVB-T
antenna
Select supply voltage no (0V) / yes (5V).
If you use a DVB-T antenna that requires a supply
voltage (active antenna) and which is not already
supplied via a power adaptor, then select yes (5V)
for the antenna’s power supply.
How to align your DVB-T antenna is described in
chapter System settings, section Connections
– Antenna DVB.
Proceed to next step.
