Loewe PLA 5303 PL - Page 55

3 - 8
Basic Board Art.-Nr. 87715.071/073/074
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
R555 1K8 G 0204 ..................................... Resistor .......................................367-20334
R557 1R5 J SI R17,5 0,5 W ....................... Resistor ......................................... 366-20386
R558 1R5 J SI R17,5 0,5 W ....................... Resistor ......................................... 366-20386
R560 10K F 0204 ........................................ Resistor ......................................... 367-20347
R561 3K9 F 0204 ......................................... Resistor ......................................... 367-20341
R565 40K2 F 0204 ....................................... Resistor ......................................... 367-26914
R566 82K G 0207 ....................................... Resistor ......................................... 367-10885
R567 470R J 0207 ...................................... Resistor ......................................... 366-20661
R569 470R J 0207 ...................................... Resistor ......................................... 366-20661
R574 0R82 K 4,00W R15 ............................. Resistor ......................................... 368-11091 074
R574 0R68 K 4,00W R15 ............................. Resistor ......................................... 368-21294 073
R574 1R J 2,00W R15 ................................ Resistor ......................................... 368-22719 071
R578 82K G 0207 ....................................... Resistor ......................................... 367-10885
R579 40K2 F 0204 ....................................... Resistor ......................................... 367-26914
R583 390K G 0204 ..................................... Resistor ......................................... 367-16791
R590 10R J 0207 ........................................ Resistor ......................................... 366-77101
R591 1R J 0207 .......................................... Resistor ......................................... 366-20649
R592 1R J 0207 .......................................... Resistor ......................................... 366-20649
R612 0R56 J 10,0W ...................................... Resistor ......................................... 368-28210
R613 0R68 J 7,00W R22,5 ........................... Resistor ......................................... 368-27914
R619 DUO-PTC 3R ........................................ PTC Resistor ................................. 372-27970 073
R621 56K J 0414 1,00W R15 ..................... Resistor ......................................... 367-22396
R622 820K J 0207 ...................................... Resistor ......................................... 366-16437
R625 680K J 0207 ...................................... Resistor ......................................... 367-27264
R626 22R J 0207 ........................................ Resistor ......................................... 366-20655
R628 39K J 3W RM20 ................................ Resistor ......................................... 367-22403
R629 22R J 0207 ........................................ Resistor ......................................... 366-20655
R632
82R J 0207 ........................................ Resistor ......................................... 366-12554
R633 2K2 J 0207 ........................................ Resistor ......................................... 366-81024
R634 680K J 0207 ...................................... Resistor ......................................... 367-27264
R639
10M J 0411........................................ Resistor ......................................... 367-19664
R639 10M J 0411 ........................................ Resistor ......................................... 367-27946
R647 100K J 0207 ...................................... Resistor ......................................... 366-16330
R651 18K G 0207 ....................................... Resistor ......................................... 367-11559
R652
1R K SI0207 ...................................... Resistor ......................................... 366-12276
R653 100R J 0207 ...................................... Resistor ......................................... 366-73257
R654 100R J 0207 ...................................... Resistor ......................................... 366-73257
R660 1K8 G 0204 ........................................ Resistor ......................................... 367-20334
R660 1K8 G SI 0204 geschnitten ................ Resistor ......................................... 367-20334Y03 073
R661
33K F 0204 ........................................ Resistor ......................................... 367-18769 073
R661 39K F 0204 ........................................ Resistor ......................................... 367-28894 071
R661 39K F 0204 ........................................ Resistor ......................................... 367-28894 073
R662 3K6 G 0204 ........................................ Resistor ......................................... 367-11486 071
R662 3K6 G 0204 ........................................ Resistor ......................................... 367-11486 073
R662
3K3 F 0204 ......................................... Resistor ......................................... 367-14897 074
R663 220K F 0207 ...................................... Resistor ......................................... 367-28413
R665 56K J 0414 1,00W R15 ..................... Resistor ......................................... 367-22396
R666 18K F 0204 ........................................ Resistor ......................................... 367-18527
Basic Board Art.-Nr. 87715.071/073/074
Pos.Nr. Bestell-Bezeichnung Description Bestell-Nr. Var.
Item N ° . List Part N ° . Var.
R668 Resistor ................................................. 366-16330
R681 3R3 J 0207 ......................................... Resistor ......................................... 366-77754
R682 33R J 0207 ........................................ Resistor ......................................... 366-22944
R683 470R J 0207 ...................................... Resistor ......................................... 366-20661
R684 6K8 J 0207 ......................................... Resistor ......................................... 366-20652
R685 68R J 3,00W RM20 ........................... Resistor ......................................... 367-22942 073
R686
0R1 K SI 0207 .................................. Resistor ......................................... 366-10905Y09
R687 0R1 K SI 0207 .................................. Resistor ......................................... 366-10905Y09
R688 1R J 0207 .......................................... Resistor ......................................... 366-20649
R689 1R J 0207 .......................................... Resistor ......................................... 366-20649
R690
1R K SI0207 ...................................... Resistor ......................................... 366-12276
R691 100R J 0207 ...................................... Resistor ......................................... 366-73257
R692 100R J 0207 ...................................... Resistor ......................................... 366-73257
Tuner/ZF / Tuner/IF Art.-Nr. 87507.051
Pos.Nr. Bestell-Bezeichnung Bestell-Nr. Var.
Item N ° . Description List Part N ° . Var.
VERBINDUNGSLEITUNG CONNECTING CABLES
50 Antennenkabel 2.4m mit Winkelstecker . Connecting Cable .......................... 169-27470001 051
INTEGR.SCHALTUNGEN INTEGRATED CIRCUITS
I4500 IC TDA5637 SOT340 ........................ Integrated Circuit ........................... 350-27278 051
I4600 IC TSA5523M SOT266....................... Integrated Circuit ........................... 350-27275 051
I4800 IC TDA9817 SDIP24 ......................... Integrated Circuit ........................... 349-27337 051
I4800 IC TDA9817 TS-SSOP24 .................. Integrated Circuit ........................... 350-28929 051
DIODEN DIODES
D4203 BB 640 SOD323 .................................. Diode ............................................. 351-26568 051
D4204 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4222 BB 640 SOD323 .................................. Diode ............................................. 351-26568 051
D4241 BB 640 SOD323 .................................. Diode ............................................. 351-26568 051
D4242 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4303 BB 639 SOD323 .................................. Diode ............................................. 351-26571 051
D4304 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4322 BB 639 SOD323 .................................. Diode ............................................. 351-26571 051
D4341 BB 639 SOD323 .................................. Diode ............................................. 351-26571 051
D4403 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4422 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4441 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4508 BB 640 SOD323 .................................. Diode ............................................. 351-26568 051
D4527 BB 639 SOD323 ............................... Diode ........................................... 351-26571 051
D4551 BB 535 SOD323 .................................. Diode ............................................. 351-26570 051
D4806 BAV 99W SOT323 ............................... Diode ............................................. 351-27469 051
QUARZE/FILTER QUARTZES
X4831 Piezo Filter 4,5 MHz ............................ Ceramic Filter ................................ 386-27305020 051
