Loewe PLA 5303 PL - Page 56

3 - 9
Tuner/ZF / Tuner/IF Art.-Nr. 87346.050
Pos.Nr. Bestell-Bezeichnung Bestell-Nr. Var.
Item N ° . Description List Part N ° . Var.
SPULEN COILS
S4110 HF-Relais G5Y-1-H 5VDC ..................... Relay ............................................. 387-27950 050
L4193 Spule ..................................................... Coil ................................................ 297-27571001 050
L4201 Spule ..................................................... Coil ................................................ 297-27571001 050
L4202 Spule kpl. .............................................. Coil ................................................ 297-28046001 050
L4231 Spule ..................................................... Coil ................................................ 297-27569001 050
L4232 Spule ..................................................... Coil ................................................ 297-27569001 050
L4233 Spule ..................................................... Coil ................................................ 297-27561001 050
L4301 Spule ..................................................... Coil ................................................ 297-27566001 050
L4302 Spule ..................................................... Coil ................................................ 297-27561001 050
L4311 Spule ..................................................... Coil ................................................ 297-27571001 050
L4331 Spule ..................................................... Coil ................................................ 297-27561001 050
L4332 Spule ..................................................... Coil ................................................ 297-27683001 050
L4342 Spule ..................................................... Coil ................................................ 297-27553001 050
L4351 Spule ..................................................... Coil ................................................ 297-27563001 050
L4352 Spule ..................................................... Coil ................................................ 297-27563001 050
L4401 Spule ..................................................... Coil ................................................ 297-27562001 050
L4402 Spule ..................................................... Coil ................................................ 297-27553001 050
L4411 Spule ..................................................... Coil ................................................ 297-27568001 050
L4422 Spule ..................................................... Coil ................................................ 297-27559001 050
L4431 Spule ..................................................... Coil ................................................ 297-27546001 050
L4432 Spule ..................................................... Coil ................................................ 297-27683001 050
L4441 Spule ..................................................... Coil ................................................ 297-27561001 050
L4442 Spule ..................................................... Coil ................................................ 297-27683001 050
L4451 Spule ..................................................... Coil ................................................ 297-27682001 050
L4452 Spule ..................................................... Coil ................................................ 297-27682001 050
L4503 Spule ..................................................... Coil ................................................ 297-27564001 050
L4523 Spule ..................................................... Coil ................................................ 297-27552001 050
L4543 Spule ..................................................... Coil ................................................ 297-27548001 050
L4546 Spule ..................................................... Coil ................................................ 297-27559001 050
L4816 Spule ..................................................... Coil ................................................ 297-27743 050
INTEGR. SCHALTUNGEN INTEGRATED CIRCUITS
I4500 IC TDA 5637 BM SMD ........................ Integrated Circuit ........................... 350-27278 050
I4600 IC TSA 5523 M SMD ........................... Integrated Circuit ........................... 350-27275 050
I4800 IC TDA 9817 V1 ................................... Integrated Circuit ........................... 349-27337 050
TRANSISTOREN TRANSISTORS
Q4110 BCR 198 W SMD ................................. Transistor ...................................... 344-27269 050
Q4210 BF 1100W-R SMD ................................ Transistor ...................................... 344-27268 050
Q4310 BF 1100W-R SMD ................................ Transistor ...................................... 344-27268 050
Q4410 BF 1100W-R SMD ................................ Transistor ...................................... 344-27268 050
Q4836 BC 847 B SMD ..................................... Transistor ...................................... 344-14974 050
Q4853 BC 847 BW SMD.................................. Transistor ...................................... 344-27272 050
DIODEN DIODES
D4110 BAS316 SOD323 ................................. Diode ............................................. 351-27952 050
D4203 BB 640 SMD ........................................ Diode ............................................. 351-26568 050
D4204 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4222 BB 640 SMD ........................................ Diode ............................................. 351-26568 050
Tuner/ZF / Tuner/IF Art.-Nr. 87346.050
Pos.Nr. Bestell-Bezeichnung Bestell-Nr. Var.
Item N ° . Description List Part N ° . Var.
D4241 BB 640 SMD ..................................... Diode ...........................................351-26568 050
D4242 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4303 BB 639 SMD ........................................ Diode ............................................. 351-26571 050
D4304 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4322 BB 639 SMD ........................................ Diode ............................................. 351-26571 050
D4341 BB 639 SMD ........................................ Diode ............................................. 351-26571 050
D4403 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4422 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4441 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4508 BB 640 SMD ........................................ Diode ............................................. 351-26568 050
D4527 BB 639 SMD ........................................ Diode ............................................. 351-26571 050
D4551 BB 535 SMD ........................................ Diode ............................................. 351-26570 050
D4806 BAV 99 W SMD .................................... Diode ............................................. 351-27469 050
QUARZE / FILTER QUARTZES
08 Label weiß 42x10 bedruckt.................... Adhesive Label .............................. 220-21812050 050
10 Quarz 4,0 MHz R5 ............................... Crystal Oscillator ........................... 385-27752 050
X4651 Quarz 4,0 MHz HC49U3 R5 ................ Crystal Oscillator ........................... 385-27752Y20 050
X4701 Filter OFW K 6263 K ............................. Filter .............................................. 290-25214 050
X4751 Filter OFW K 9461-M............................. Filter .............................................. 290-25216Y20 050
X4831 Piezo Filter 4,5 MHz ............................. Ceramic Filter ................................ 386-27305020 050
SPEZIALTEILE SPECIAL PARTS
10 Filter OFW K 9461-M............................. Filter .............................................. 290-25216 050
20 Deckel ................................................... Lid ................................................. 501-87236011 050
21 Deckel ................................................... Lid ................................................. 501-87236011 050
46 Abschirmung ......................................... Screening ...................................... 509-87544001 050
47 Abschirmung ......................................... Screening ...................................... 509-87545001 050
48 Abschirmung 3 (Tuner US) ................... Screening ...................................... 509-87588001 050
P4821 Potentiometer 10K ................................. Potentiometer ................................ 375-27744 050
W4100 Koax-Buchse ......................................... Socket ........................................... 323-27599 050
W4150 Koax-Buchse ......................................... Socket ........................................... 323-27599 050
W4200 Kontaktleiste 7-pol. RM 5,08 ................. Contact Ledge ............................... 326-27320007 050
W4200 Kontaktleiste 7-pol. ................................ Contact Ledge ............................... 326-27320017 050
W4800 Kontaktleiste 6-pol. ................................ Contact Ledge ............................... 326-27320006 050
W4800 Kontaktleiste 6-pol. ................................ Contact Ledge ............................... 326-27320016 050
