18 Battle Ax Skid Loader OM
Operating Instructions
Log Moving
Disengage hydraulic power to rotor before moving logs
and brush with pusher bars.
Raise the loader lift arms and tilt the Battle Ax forward
until the push bar extensions are over the log or item
being moved. Lower the lift arms and position the log
between push bar extensions and the Battle Ax. Move
the loader backwards, dragging the log to the desired
location.
Hydraulic Hose Storage
When not in use, protect the hose couplers by securing
the hydraulic hoses in the storage position on the left
side pusher arm.
