29Battle Ax Skid Loader OM
Parts Identiļ¬cation
Battle Ax Body Assembly
# QTY. PART # DESCRIPTION
1
1 N38523 PUSHER, 61 W/DECALS
1 N68438 PUSHER, 71 W/DECALS
2 6 N64492 BOLT, 1-14 X 4" GR. 8 FN. THR
3 6 4166 WASHER, 1" LOCK
4 5 4490 NUT, 1"-14UNF STANDARD
5 1 N45262 SHIELD, MOTOR
6 5 4195 BOLT, 3/8" X 1" GRADE 5
7 5 N37756 WASHER, NORD-LOCK 3/8" SP
8 1 N45488 PLATE, WELDMENT MOTOR
9 1 N27483 BOLT, 1/2" X 5" GR 5 FL TH
10 2 4250 NUT, STANDARD 1/2
11 1 4068 WASHER, 1/2" SAE FLAT
12 1 4304 HOSE, GREASE 1/8" X 15"
13 1 N49680 COVER, WELDMENT BELT BOTTOM
14 7 N37780 WASHER, NORD-LOCK 1/2" SP
15 4 4012 BOLT, 1/2" X 1-1/4" GRADE 5
16 2 4375 PIN, ROLL 3/16" X 1"
17
1 N20102 ROD, CARBIDE 61" CHAIN
1 N20166 ROD, CARBIDE 71" CHAIN
18
66 N15589 CHAIN, CARBIDE AX REAR 61"
76 N15589 CHAIN, CARBIDE AX REAR 71"
19 1 N67045 TUBE, PUSHER SHORT W/BUSHING
20 4 N26748 BOLT, 1/2" X 1" SER FLG
21 1 N68396 COVER, HOSE W/DECALS
22 1 N67081 TUBE, PUSHER LONG W/BUSHING
23 1 N25125 ELBOW, 90 DEG - 4FJIC - 4MJIC
24 1 4304-10 BULKHEAD, FITTING-GREASE HOSE
25 1 N17007 GREASEZERK, 1/8" NPT
26
3
4011 BOLT, 1/2" X 1" GRADE 5
27 1 N49792 PLATE, SUPPORT MOTOR ASSY
28
1
4472 ELBOW, 90 1/8
To Next Page
