31Battle Ax Skid Loader OM
Battle Ax Body Assembly (Cont’d)
Parts Identification
# QTY. PART # DESCRIPTION
1 1 N89749 PLATE, BELT COVER
2 1 N134034 PLATE, MANUAL COVER
3 2 N18360 BOLT, 1/2 X 1-1/4 SER FLG
4 3 N26748 BOLT, 1/2" X 1" SER FLG
5 1 N45488 PLATE, WELDMENT MOTOR
6 8 4055 NUT, LOCK 5/8" TOP
7 1 N47366 SKID SHOE
8 8 4386 BOLT, CARRIAGE 5/8" X 1-1/2"
9 4 4466 BOLT, 1/2" X 1-1/2" GRADE 8
10 6 N16472 WASHER, 1/2 NORDLOCK
11 1 N41636 PLATE, MOUNT MOTOR
12 4 N28567 WASHER, 3/4 NORDLOCK SP
13 4 N16349 BOLT, 3/4 X 2-1/2 FN TH GR 8
14 1 N49750 SKID SHOE, NON DRIVEN
15 1 N68442 PLATE, MOUNT STEP
16 5 N26743 BOLT, 3/8" X 1" SER FLG
17 5 4012 BOLT, 1/2" X 1-1/4" GRADE 5
18 4 N37780 WASHER, NORD-LOCK 1/2" SP
19 1 N17007 GREASEZERK, 1/8" NPT
20 1 4304-10 BULKHEAD, FITTING-GREASE HOSE
21 1 4304 HOSE, GREASE 1/8" X 15"
22 1 N25125 ELBOW, 90 DEG - 4FJIC - 4MJIC
23 1 N68422 COVER, NON-DRIVEN W DECALS
24 1 4472 ELBOW, 1/8" 90 DEG. STREET
25 1 4468 SCREW, 1/2" x 20UNF x 1 1/4" FN TD FL HD CAP
26 1 4076 WASHER, 1/2" EXT CNTSK LOCK
27 1 4085 PIN, ROLL 3/16" x 3/4"
28 1 4075 WASHER, 2 -5/8" OD BEARING RETAINER
29 8 N20043 BOLT, 1/2" x 2 - 1/4" FN TD GR 8
30 8 N16472 WASHER, 1/2" NORDLOCK
31 2 N16417 BEARING, 2 - 3/16" PILOT ROLLER
32 10 N13747 BOLT, 5/8" X 1-3/4" FN TH GR 8
33 10 N16473 WASHER, 5/8" NORDLOCK
34 2 N41590 MOUNT, CARBIDE ROTOR BEARING
35 2 N41572 ANTIWRAP, CARBIDE MACHINED
36 1 N16445 BUSHING, 2 - 3/16" ID x 2 - 3/4" OD
37
1 203047* ROTOR, 61" BS W/CARBIDE
1 N49368* ROTOR, 61" BS W/QUADCO
1 203050** ROTOR, 71" BS W/ CARBIDE
1 N49371** ROTOR, 71" BS W/ QUADCO
1 203177*** ROTOR, 61" BS W/ QUADCO H
1 203179*** ROTOR, 71" BS W/ QUADCO H
* Parts breakdown of 203047 and N49368 is on page 54.
** Parts breakdown of 203050 and N49371 is on page 55.
*** Parts breakdown of 203177 and 203179 is on page 56.
