37Battle Ax Skid Loader OM
Parts Identiļ¬cation
Hydraulics, Parker Motor with Brake
# QTY. PART # DESCRIPTION
1 4 N16349 BOLT, 3/4 X 2-1/2 FN TH GR 8
2 4 N28567 WASHER, 3/4 NORDLOCK SP
3 1 N45488 PLATE, WELDMENT MOTOR
4 1 N41636 PLATE, MOUNT MOTOR
5 1 N51193 OHLA, 900 W C TO D ADAPTER
6 4 4475 BOLT, 3/4" X 2-1/4" GRADE 5
7 4 N16474 WASHER, 3/4 NORDLOCK
8 1 N38488 MOTOR, VARIABLE 80CC-110CC
9 2 N20818 ELBOW, 90DEG 16MJIC-16 CODE 62
10 1 N28903 ELBOW, 90DG TUBE 16MJIC-16FJIC
11 1 N19271 ADAPTER, 16MJIC - 16FJIC SWVL
12 1 N19272 TEE, 16MJIC-16FJIC-16MJIC
13 1 N30420 ADAPTER, -16FJIC -6MJIC
14 1 N19270 ELBOW, 90 DEG - 16MJC - 16FJC
15 1 N16166 HOSE, 3/8" X 24" -6FJX -8MOR
16 2 N90323 HOSE, 1 64 - 16FJIC - 16 90CD62
17 1 N38498 HOSE, 1/4 100 -6FJIC -4FPSWIVL
18 1 N16162 ELBOW, 1/4" BLK 90 DEG STREET
19 1 N16163 GAUGE, 0-6000PSI 4" PRESS
20 1 N38500 HOSE, 1/2 X 80 -8FJIC -8FJIC
21 1 N11953 TEE, 8MJIC-8MOR-8MJIC
22 1 N157054 VALVE, RELIEF 100PSI
23 1 N28823 04MJ-08MOR STRAIGHT
24 4 N20288 KIT, SPLIT FLANGE SFXK-16
25 2 N41121 ELBOW, 90 DEG -16MJIC-16MOR
26 1 N21669 VALVE, OPEN LOOP CW
27 1 N38519 ADAPTER, BULKHEAD 45DEG -4MJIC
28 1 N69021 HOSE, 1/4 X 14 -4FJIC -4FJIC
29 1 N28907 ELBOW, 90DEG -6MJIC -4MOR
30 2 N90130 HOSE, 1 84 -16FJIC -16MORB
Hydraulics parts list and drawing continued on the following two pages.
