39Battle Ax Skid Loader OM
Hydraulics, Parker Motor with Brake (Cont’d)
# QTY. PART # DESCRIPTION
31 2 N63426 CLAMP, HOSE
32 1 N13811 BOLT, 1/4" X 2-3/4" GRADE 5
33 1 N90265 WRAP, HOSE 76
34 1 N90142 HOSE, 1/2 100 -8FJIC -8MORB
35 1 N32002 PLUG, 3/8 SCH 40 X .25
36 1 N15895 CAP, 1/2 ALUMINUM HOSE
37 2 N28108 ADAPTER, - 12MOR - 16FOR
38 6 4064 WASHER, FLAT 3/8"
39 2 N15893 CAP, 3/4" ALUMINUM HOSE
40 4 4237 NUT, 5/16" STANDARD
41 4 4460 WASHER, 1/4" SAE FLAT
42 7 4195 BOLT, 3/8" X 1" GRADE 5
43 2 N16470 WASHER, 3/8 NORDLOCK
44 1 N16124 MOUNT, ACCUMULATOR
45 1 N87003 ACCUMULATOR, 5000PSI 100PSI PC
46 2 N16125 U-BOLT, 5/16 X 2-1/2 X 3-1/2
47 1 N29731 ADAPTER, 8MJC - 12MOR
48 1 N24827 ELBOW, 90 DEG - 8FJC - 8MJC
Parts Identification
