41Battle Ax Skid Loader OM
Hydraulics, Parker Motor No Brake
# QTY. PART # DESCRIPTION
1 1 N38488 MOTOR, VARIABLE 80CC-110CC
2 3 N37780 WASHER, NORD-LOCK 1/2" SP
3 3 4011 BOLT, 1/2" X 1" GRADE 5
4 4 4475 BOLT, 3/4" X 2-1/4" GRADE 5
5 4 N16474 WASHER, 3/4 NORDLOCK
6 1 N51193 OHLA, 900 W C TO D ADAPTER
7 1 N41636 PLATE, MOUNT MOTOR
8 6 N16472 WASHER, 1/2 NORDLOCK
9 4 4466 BOLT, 1/2" X 1-1/2" GRADE 8
10 1 N45488 PLATE, WELDMENT MOTOR
11 4 N28567 WASHER, 3/4 NORDLOCK SP
12 4 N16349 BOLT, 3/4 X 2-1/2 FN TH GR 8
13 3 4250 NUT, STANDARD 1/2
14 1 N49792 PLATE, SUPPORT MOTOR ASSY
15 1 N155816 HOSE, 1/4 X 31 -4FPSW -6FJIC
16 2 N20818 ELBOW, 90DEG 16MJIC-16 CODE 62
17 1 N19271 ADAPTER, 16MJIC - 16FJIC SWVL
18 1 N19272 TEE, 16MJIC-16FJIC-16MJIC
19 1 N19270 ELBOW, 90 DEG - 16MJC - 16FJC
20 1 N30420 ADAPTER, -16MJIC -6MJIC
21 1 N28903 ELBOW, 90DG TUBE 16MJIC-16FJIC
22 1 N38500 HOSE, 1/2 80 -8FJIC -8FJIC
23 1 N24827 ELBOW, 90 DEG - 8FJC - 8MJC
24 1 N29731 ADAPTER, 8MJC - 12MOR
25 4 N20288 KIT, SPLIT FLANGE SFXK-16
26 2 N90130 HOSE, 1 84 -16FJIC -16MORB
27 2 N28108 ADAPTER, - 12MOR - 16FOR
28 6 4064 WASHER, FLAT 3/8"
29 2 N15893 CAP, 3/4 ALUMINUM HOSE
30 1 N15895 CAP, 1/2 ALUMINUM HOSE
Hydraulics parts list and drawing continued on the following two pages.
Parts Identiļ¬cation
