LOFTNESS 61 - Overhung Load Adapter (N51193)

45Battle Ax Skid Loader OM
Hydraulics, Muncie Motor
# QTY. PART # DESCRIPTION
1 2 N49295 HOSE, 3/4" X 86" -12FJIC -12MOR
2 1 N24823 DECAL, RETURN
3 6 4064 WASHER, FLAT 3/8"
4 2 N15893 CAP, 3/4 ALUMINUM HOSE
5 1 N15895 CAP, 1/2 ALUMINUM HOSE
6 1 N32002 PLUG, 3/8 SCH 40 X .25
7 1 N24822 DECAL, PRESSURE
8 1 N90265 WRAP, HOSE 76
9 2 N49293 HOSE, 3/4" X 61"-12FJIC-12FJIC
10 1 N20389 HOSE, 1/2" X 144" - 8FJX-8MOR
11 2 N25883 ELBOW, 45 DEG - 12MJC - 12MOR
12 2 N31225 ADAPTER, 20MOR - 12FOR
13 1 N34676 MOTOR, MUNCIE 62.9CC
14 1 N34763 ELBOW, 90 -8MJIC -4MORB
15 6 4513 BOLT, 1/2" X 1-1/4" GRADE 8
16 10 N16472 WASHER, 1/2 NORDLOCK
17 1 N16416 ADAPTER, OVERHUNG LOAD MOTOR
18 1 N49314 PLATE, MOTOR SLIDER SHIM
19 1 N49114 G4 MUNCIE MOTOR MOUNT
20 4 N31536 BOLT, 1/2 X 1-3/4 12 PT GRD8
21 4 N28567 WASHER, 3/4 NORDLOCK SP
22 4 N16509 BOLT, 3/4" X 2" FINE THREAD GRADE 8
23 2 4465 BOLT, 1/2" X 1" GRADE 8
24 3 N37780 WASHER, NORD-LOCK 1/2" SP
25 1 N49108 G4 MUNCIE MOTOR BRACKET
26 1 4466 BOLT, 1/2" X 1-1/2" GRADE 8
27 1 4486 WASHER, 1/2" FLAT
28 1 4250 NUT, STANDARD 1/2
29 1 N13811 BOLT, 1/4" X 2-3/4" GRADE 5
30 2 N49110 CLAMP, HOSE
31 2 4538 BOLT, 3/8" X 2-3/4" GRADE 5
Hydraulics parts list and drawing continued on the following two pages.
Parts Identification
