47Battle Ax Skid Loader OM
# QTY. PART # DESCRIPTION
32 2 N13876 ELBOW, 90 DEG - 16MOR - 12MJIC
33 1 N34677 MANIFOLD, CROSS PORT RELIEF
34 1 N28907 ELBOW, 90DEG -6MJIC -4MOR
35 2 4011 BOLT, 1/2" X 1" GRADE 5
36 2 N29075 NUT, LOCK 1/2" SERATED FLANGE
37 1 N49315 G4 MUNCIE VALVE BRACKET
38 2 4233 NUT, STANDARD 3/8"
39 2 N16174 ELBOW, 45 DEG 12MJIC - 16MOR
40 2 N21333 ELBOW, 90 DEG-12MJIC-12FJIC
41 1 N38498 HOSE, 1/4 100 -6FJIC -4FPSWIVL
Hydraulics, Muncie Motor (Cont’d)
Parts Identification
