Programming System Features [continued]
Programming Guide
This feature allows you to activate the Door Station Call Forwarding feature. When the Door Station
Speaker Button is pressed and the call is not answered from one of the premise phone(s) within a
specific time limit, the TeleDoorBell will then pick-up the phone line and dial the pre-programmed call
forwarding number and if answered, allows the user to communicate to the Door Station Speaker
remotely and perform all the functions as though they were within the premises.
1) PRESS
2) Listen for
**6
__
*
#
(1) BEEP.
3) Enter the Phone Number you wish to Call Forward to. 1
4) PRESS to SAVE
(up to 30 Digits)
NOTE: To DISABLE the Call Forwarding feature see USER GUIDE Door Station Call Forwarding Functions Page 13.
To Change a Door Station Call Forwarding Number ... Repeat STEPS 1-4.
..... 30
Note: ENTER for inserting a PAUSE (6 Second Delay) anywhere in the dialing sequence.
(2) BEEPS will be heard for acceptance of programming.
Page 15
Programming the Door Station Call Forwarding Phone# **6
Continued
Continued
on Page-16
This feature allows you to program the relay’s activation timing. Relay timing setting can be from 0.5
seconds to 49 seconds, latching or for closure upon door station button press.
1) PRESS **8
2) Select RELAY you wish to program: PRESS
3) Enter RELAY 2-Digit Timing Setting:
4) Listen for
1234OR OR OR .
(2) BEEPS for acceptance of programming.
* A202 models Relays #1 and #2 are programmable.
* A204 models Relays #1, #2, #3 and #4 are programmable.
01 98- = in Seconds, [FACTORY DEFAULT SETTING = 6]
NOTE: In a power failure situation, any programmed LATCHED Relay(s) in the LATCHED [ON] position will be reset to UN-
LATCHED State [OFF]. This is to prevent any devices from inadvertently being activated for an indefinite period of time.
Relay Timing Configuration **8
Call Forward Hang-Up Time **9
This feature allows the call forwarding hang up time to be shortened from the factory default of
twenty (20) minutes for specialized applications.
1) PRESS
2) Listen for
4) Listen for
**9
(1) BEEP.
3) Enter - seconds. Note: Entering will set the hang up time to the factory default of
twenty (20) minutes.
01 98 99
(2) BEEPS for acceptance of programming.
