Table of Contents
Important Notes and Safety Instructions ........................................... Pg 1
“X” Series Specifications .............. ............................................................. Pg 2
“S” Series Specifications............................................................................. Pg 3
Features and Parts Listing.......................................................................... Pg 4
Controller Anatomy .................................................................................. Pg 5
“X” Series Door Station Wiring.................................................................... Pg 6
“S” Series Door Station Wiring.................................................................... Pg 7
Controller Wiring Diagram .................................................................... Pg 8
TBG-1 Installation Diagram........................................................................ Pg 9
DSL Installation Diagram ..........................................................................Pg 10
KSU/PBX Installation Diagram.... ............................................................ Pg 11
M203HIFI Installation Diagram... ............................................................. Pg 12
“X” Series Programming Guide ....................................................... Pg 13-16
“HI-FI” Series User/Programming Guide ..................................................Pg 17
TroubleShooting Guide....................................................................... Pg 18-19
Warranty Information.......................................................................... Pg 20-21
1) Certain cordless phones may not ring or ring properly when Door Station Speaker Button is pressed. Phone will still be operational
and all functions are still active and accessible.
2) An average of (6) six phones limit will apply for having connected phones ring. Exceeding this limit may result in some phone(s) not
ringing. (Results and phone limitations may vary depending on types of phones and the loads (LN#) they present to the overall
system).
NOTE:
3) Remote Call Answer may not be compatible with various types of add-on phone features such as Ident-A-Call, Call Display Long
Distance ringing or any other feature(s) which will change or produce a different ringing pattern of an incoming call.
4) System may not be compatible with various voice-mails including cell phones when enabling the Door Station Call Forwarding
feature.p (Results and features may vary with your local service provider / supplier).
5) If a Logenex DSL 3-Port High-Speed Filter (LX-DSL3F) is installed and the user places a phone caller ON-HOLD using the
command to communicate to a Visitor at the Door Station, a low level cross-talk may be heard by the user when communicating to
the Visitor at Door Station.
6) Some Phone Service Providers, phone features and/or command functions may not be compatible with the product(s)
*4
TeleDoorBell .
The Load Number (LN) assigned to each terminal device denotes the percentage of the total load to be
connected to a telephone loop which is used by the device to prevent overloading.
COMPATIBILITY ISSUES
