Logik L19LIDI9WE

8
678910 11 12 13 14 15 16
6) DVD VIDEO OUT jack
7) Power Cord
8) HDMI in jack
(applicable to
model L19LIDI9E / L19LIDI9WE
/ L22LIDI9E / L22LIDI9WE only)
9) Audio jack (PC IN)
10) MONITOR/VGA jack (PC IN)
11) SCART jack (AV IN 2)
12) TV Antenna
13) VIDEO IN jack (AV IN 1)
14) AUDIO IN jacks (Left/Right)
15) PHONES jack
16) COMMON INTERFACE slot
LCD TV
FRONT VIEW
BACK VIEW
1) Color LCD Screen
2) Tweeters
3) Remote Sensor
Donotblockthissensorortheremote
controlwillnotwork.

Standby Indicator
 IndicateswhethertheunitisONorin
STANDBY(OFF)mode.
 LightOn:TheunitisinSTANDBY.
 LightOff:TheunitisturnedON.
4) Dock for iPod
®
5) Speakers
123425
