18
4. Now pull the door forward off the oven. Releasing
both hinge sections from the slots.
3. Slightly close the door and lift. The notch on the
bottom of the hinge will disengage.
To replace the door, repeat the above steps on reverse
order. Ensure to locate the hinge correctly, place the
grove of the hinge directly on the edge of the door
frame. Push forward the swivel retainers to the original
position and gently close the door. If the door does not
close properly, repeat the steps again.
* All images are for indication only; please refer to your individual unit for actual item.
