Configuration
Default Device Numbers
Following is the default Device COM Port map that ships with the Artisan.
These defaults are designed to suit most standard consoles, up to 30 faders. In some cases it may be
necessary to override the default mapping to support non-standard requirements.
Port Connector Standard Module Alternative Channel (dec) Port 1 Device (hex)
1 A 1 Effects Module Dynamically assigned Dynamically assigned
2 A 2 Fader 1/2 1 & 2 OB & OC
3 A 3 Fader 3/4 3 & 4 OD & OE
4 A 4 Fader 5/6 5 & 6 OF & 10
5 A 5 Fader 7/8 7 & 8 11 & 12
6 A 6 Fader 9/10 9 & 10 13 & 14
7 A 7 Fader 11/12 11 & 12 15 & 16
8 A 8 Fader 13/14 13 & 14 17 & 18
9 A 9 Fader 15/16 15 & 16 19 & 1A
10 A 10 Fader 17/18 17 & 18 1B & 1C
11 A 11 (under) External Softkey Narrow Softkey 77 & 78 57 & 58
12 A 12 (under) Meter Bridge A 73 & 74 53 & 54
13 B 1 Fader 19/20 19 & 20 1D & 1E
14 B 2 Fader 21/22 21 & 22 1F & 20
15 B 3 Fader 23/24 23 & 24 21 & 22
16 B 4 Fader 25/26 25 & 26 23 & 24
17 B 5 Fader 27/28 27 & 28 25 & 26
18 B 6 Fader 29/30 29 & 30 27 & 28
19 B 7 Narrow Softkey 75 & 76 55 & 56
20 B 8 Master Module 41 - 55 33 - 41
21 B 9 Monitor Module 56 - 63 42 - 49
22 B 10 Wide Softkey 71 & 72 51 & 52
23 B 11 (under) External Softkey Narrow Softkey 79 & 80 59 & 5A
TIP: Only one Artisan surface is supported per Audio Engine. When addressing Artisan
modules with CHAN notation, always use SURF1 as the surface.
