4
Configuration
Bus Numbers
MLX-WSOFT
MLX-
NSOFT
32
33
34
35
36
37
38
39
40
41
42
43
44 45
46 47
48 49
Timer Buttons
Use AE effect
command to control
Scene Buttons
BUS32 to 43
TAKE (BUS29)
CANCEL (BUS30)
SELECT (BUS31)
Screen Text Buttons
BUS79 to 84
Misc Buttons
BUS85 to 87
Softkey Buttons
BUS88 to 99
Offline Source
DEV46
BUS16 to 19
Direct TB
DEV45
BUS16 to 19
17
18 19
16 17
18 19
16
17
18 19
16
17
18 19
16 17
18 19
16
32 33
34 3 5
36 37
38 3 9
40 41
42 43
30 29
31
79
80
81
82
83
84
85
86
87
88 89 90 91
92 93 94 95
96 97 98 99
Studio 2 Monitor
DEV43
BUS 16 to 19
Studio 1 Monitor
DEV42
BUS16 to 19
Control Room Monitor
DEV44
BUS16 to 19
Softkey Buttons
BUS44 to 49
Buttons
BUS32 to 43
Port B10 (de
f
ault)
Switches/Top Screen: DEV52
Lamps/Bottom Screen: DEV51
MTK-MON
Port B9 (default)
Devices shown above
Port B7 (internal)
Switches: DEV56
Lamps: DEV55
Port A11 (under console)
Switches: DEV58
Lamps: DEV57
Port B11 (under console)
Switches: DEV5A
Lamps: DEV59
Port A12 (default)
Left Screens/Master 1 Meter/LED Text: DEV53
Right Screens/Master 2 Meter: DEV54
