- 20 -
WhentheLogiexisusedeveryday,adjustmentsandthereplacementofworn
parts might be necessary.
Adjustments and minor repairs can easily be made on the spot. Major repairs
should, however, be carried through by the dealer who has a well-trained staff and
the necessary special tools.
Before asking the dealer for assistance...
...try the fault locations key!
7.0 Fault location key
Symptoms and observations
A Stacker does not drive when the handle is tilted and drive grip turned!
- - no click can be heard from relays when the handle is tilted
- -noclickcanbeheardwhenthemultiexbuttonisactivated
- - the motor makes a humming noise
B Stacker drives slowly
C Stacker brakes when drive grip is released (handle tilted)
D Stacker does not brake when handle is tilted to upper or lower position
E Stacker brakes too little/too much
F Forksdonotliftwhen“UP”ispressed
G Noclickcanbeheardwhen“UP”ispressed
H Forksliftonlyalittle/nottomax.heightwhen“UP”ispressed
I Forksdonotsinkwhen“DOWN”ispressed
J Forks sink slowly
K The battery is not charged (no light in charging lamp)
