3.0 How to operate Logiflex Maxi
Insert key (1) and turn clockwise to
switch on control current ready for
function activation.
Note!!! Emergency stop
(2) must not be activated.
The control functions of the stacker are located in the handle (3).
- The functions are dependent on the positions of the handle!
Position A: Drive position
Drive current on
Brake deactivated
Position B: Stop/Brake/
Emergency Stop
Drive current off
Brake activated
