26
60A 100A 10A 20A
5.2 Wirring connections
Many operational disturbances are caused by bad connections in the
electrical circuit. Make sure that the connections are in order.
Check connections regularly for damage at insulating caps or bad connections
at plugs etc. Verdigris must be removed from cable plugs. Keep all screw/nut
connections tight.
Replacement:
The old fuse is to be removed and replaced by a new one of the same size.
Find out why the fuses blow!
5.1 Fuses - replacement
There are four fuses in the electrical circuit, located behind the
plate with this pictogram.
• 60 Amp fuse for Rotator
• 100 Amp fuse in the main supply from battery
• 10 Amp fuse in the control current circuit
• 20 Amp fuse for built-in charger
5.0 There must be a current supply...
