Section 3 Maintenance
3.5 Governor
1.Loosen the governor bracket nut, wave the bracket to make throttle full open.
2.Turn the governor arm right to make governor full closed ( same direction with throttle full
open), tighten the nut。
3.Check governor arm and throttle if moving freely,
4.Start engine, and allow it to warm up to the normal operating temperature. Move lever to
make engine at maximum speed. Adjust throttle lever screw to make the throttle lever not
to exceed this position.(let speed out maximum speed)
