Section 4 Disassembly and service
4.2 CONTROL BOX BRACKET
Disassembly/Reassembly
SCREW BOLT M4×55 (2)
BOLTt: M6×20
TORQUE: (8~12)N•m
ELCETRIC STARTING BOX HOLDER
4-3
FLAT WASHER (2)
