Section 4 Disassembly and service
4.8 Governor bracket and throttle control assy
Disassembly/Reassembly
4-11
Assembly: Insert
long end of hook
onto lever.
Throttle reset spring
Assembly: Put long end of
hook onto control lever
Governor spring
Nuts: M6
Bolt Quadrate Head
Governor Arm
Governor Rod
Bolt: M6×8, (2)
Torque: (8~12)N•m
SHROUD COMP
CONTROL ASSY
Engine switch
