Section 4 Disassembly and service
4.1 DRAIN BOLT
Disassembly/Reassembly
Section 4 Disassembly and service
4-2
4-1
FLAT WASHERφ10×16×1.5 (3)
BOLT: M10×
1.25
×
15
(2)
TORQUE: 22～25N.m
OIL EXTENSION ROD
