LONCIN G250F User Manual

Section 4 Disassembly and service
Disassembly/Reassembly
Note：Clean the carburetor before disassembling.
4-8
Assistant jet
Assembly:
Clean with compressed air and
lightly lubricate 0-ring before
assembling.
O-ring
Body Carburetor
Main nozzle
Assembly:
Clean thoroughly
with compressed
air before assembling
Main jet
Clean thoroughly
with compressed
air before assembling.
Float
Check for smooth movement
after assembling.
Assembling bolt
Check for fuel leaking
after assembling
Drain bolt
Float valve
Assembly: Assemble after
checking for float seat,
float valve and float valve
spring wearing.
float valve seat
REPLACE
Air pump Primer
Primer Line
Clip, (2)
Float Pin
float valve
Spring Needle Valve
O Ring Fuel Bowl
Float chamber
Gasket
Gasket
OK
Choke valve handle
