Section 4 Disassembly and service
c、Spark plug cap
Put the tester to contact the two end of the
spark plug cap and measure spark plug cap
resistance
If the resistance is out of the specification,
replace the spark plug.
.
Adjustment
Adjustment is required only when the ignition coil or the flywheel has been removed.
1. Loosen the ignition coil mounting bolts.
2. Insert the thickness gauge or a piece of paper of the proper thickness between the
ignition coil and the flywheel, both gaps should be adjusted simultaneously. Avoid the
magnet when adjusting the air gap.
3. Push the ignition coil firmly toward the flywheel and tighten the mounting bolts.
