LONCIN LC3500i User Manual

Chapter IV Disassembly & Repair
- 19 -
4-3 Diagram for disassembly
The above diagram is for quick reference for
disassembling products. In order to operate better
and more safely, please ensure to follow
above-mentioned orders.
Diagram for disassembly
of generator
Silencer
Left/right generator
casing
Shutter at tail
Control panel
Panel seat
Stator
Rotor
Combination of
rack baseplate
Rack baseplate
Support plate of
engine
Vertical framework
Air filter
Carburetor
Fan housing
Engine
Fuel tank bracket
Rack baseplate
Brake and wheel
Inverter
Cushion seat of
main engine
Fuel tank
Impeller
Left/right
appearance cover
plate
